Yak 23 "Flora"

Regular price €109,00

Yak 23 "Flora"  70mm edf -  For mini fan and 3-4 lipo or nihm cells
Thanks to Jean Tardif for the video
 Thanks to Ton van Munsteren for the video

Design Features:

  • All Formers And Ribs CNC Cut
  • Unique Tab Lock Design
  • Two Piece Design Easy transportation
  • Motor/Fan compartment Easy accesable through wing.
  • Battery Acces through Wing

Specifications:

  • Wing Area: 19 dm2
  • Wing Span; 1040 mm
  • Flight Weight: Starts at 900 grams
  • Wing Loading: 47gr dm2 to 66gr dm2
  • 3 Channel Elevator, Ailerons & Throttle

Kit Includes:

  • Photo Instructions
  • Full Size Rolled Cad Plans With All Parts Shown
  • Vacuformed Canopy.
  • Paper Intake Tube (Preprinted) , PVC Outlet Tube
  • Control Horns , Steering Cables
  • Waterslide decals.(not available) use HK decals nr HK-313000018

Required to Complete:

  • 3 Channel Radio.
  • Light weight Receiver:
  • Light weight Servos: About 9 grams (2x)
  • Motor: Hetrc edf 2W (3 lipo) or 2W-20(4 lipo)
  • Speed controller 60-80 amps
  • Wemotec Mini Fan 480
  • Battery: 3S or 4S 3200 lipo
  • Thick and Thin CA glue
  • Bungee Launch req.
  • The Yak 23 needs a 8mmx7,5mtr bungee with 8kg of pulling power.handlaunching also possible

Now some building pictures for impression.



All wood fuselage and wing. Fan unit mounted in wing pod.
