Spitfire MKI 1500mm

Regular price €169,50


3d pdf on cd you need adobe X10 or higher to view the 3d contents of the spitfire

Design Features:

  • All Formers And Ribs CNC Cut
  • Unique Tab Lock Design
  • Two Piece Design Easy transportation
  • Motor/Battery compartment Easy accesable
  • Battery Acces Through cowl opening

Specifications:

  • Wing Area: 42 dm2
  • Wing Span; 1500 mm
  • Flight Weight: Starts at 2700 grams
  • Wing Loading: 65gr dm2
  • 4 Channel Controls

Kit Includes:

  • Photo Instructions on CD and Many more Pictures
  • Full Size Rolled Cad Plans With All Parts Shown
  • Vacuformed Cowl, motor cowl, airintakes, exhaust, spinner, canopy
  • Pre designed for retracts.
  • Control Horns, Steering Cables, Hinges

Required to Complete:

  • 4 Channel Radio.Light weight Receiver:
  • Electric retract set, or air, wheels 75mm
  • Light weight Servos: About 13grams (4x ailerons elevator and rudder)
  • Motor: type NTM 41-48
  • 35-75 amp controller,
  • Some paint,glass finish
  • Battery: 4S 3700 to 6s5000 lipo
  • Thick and Thin CA glue 5-6 bottles
  • Grass or concrete airfield

Very large woodpack for the Spitfire, sheeting stringers cnc cut parts.

Now some build pictures,

Build up balsa wing ribs and formers

Balsa fuselage easy building

Vacuumformed parts make life easyer.

even a spinner is in the kit, adapt it to 2 blade or 3 blade prop template is included

Easy tail

All vacuumformed parts in the kit

Special thanks for the additional pictures to Ronald Spijkers (green version) and Res Stoer (Silver version).
