Messerschmitt M19

Messerschmitt M19

• Scale model of the German pre war civillian plane.
• All wood construction
• Easy building kit all parts cnc cut
• The M19 is Easy Flying, but is a oldtimer and should be treated that way

Design Features:

• All Formers And Ribs CNC Cut
• Unique Tab Lock Design
• Two Piece Design Easy transportation
• Motor/Battery compartment Easy accesable
• Battery Access Through hatch opening

Specifications:

• Wing Area: 32 dm2
• Wing Span; 1900 mm
• Flight Weight: Starts at 1750 grams
• Wing Loading: 55gr dm2
• 5 Channel Controls (landing flap function)

Kit Includes:

• Photo Instructions download from www.rbckitsinstructions.com
• Full Size Rolled Cad Plans With All Parts Shown
• Vacuformed Motor Cowl and dummy motor and pilot

Required to Complete:

• 4 Channel Radio.
• Light weight Receiver
• Light weight Servos: About 13grams (2x ailerons ) to 30 grams (elevator and rudder)
• Motor: type G32 550kv
• 35-75 amp controller
• Some paint,foil finish, oldtimer wheels 85-90mm
• Battery: 3S4000 lipo
• Thick and Thin CA glue 4 bottles
• Control Horns, steering cables, hinges

some building pictures, more on the cd

Build up rudder and elevator

Nice easy build up wing

Fuselage with cnc cut formers builds fast and easy

Fuselage sheeting is also cnc cut

Tail feathers are stick on and glued, easy finishing

Pre bend landing gear with functional schock absorbers from rubber band

vacuum formed parts included, the pilot here is finished it is not finished in the kit, you need to do some paintwork for this
