L-39 Albatros

Regular price €235,00

For 90mm Midi fan Evo edf and 8 cells 5000 (a FMS unit or equ will not work in rbckits edf jets)

The L39 is easy to fly easy & land and is fast


Design Features:

  • All Formers And Ribs 185 cnccut parts in balsa and ply
  • Unique Tab Lock Design
  • Removable wing for easy transportation and Storage

Specifications:

  • Wing Area: 33 dm2
  • Wing Span; 1250 mm
  • Length :1525mm
  • Flight Weight: Starts at 3900 grams
  • 6 channel, ailerons, elevator, Throttle, Retracts, flaps, nose wheel steering

Kit Includes:

  • Photos and Instructions download
  • Full Size Rolled Cad Plans With All Parts Shown
  • Vacuformed Canopy, nosecone, wingtanks, Paper inlet and outlet ducting
  • All wood and sheeting to make the L-39

There is no hardware in the L-39 kit!

Building instructions can be found here
Build steps cad can be found here

Optional cd has high res pictures

Required to Complete:

  • Any 7 Channel Radio
  • Light weight Receiver
  • Servos: About 13 grams metal gear ailerons needs stronger type 30gr
  • Motor: Hetrc EDF650/68/1500 8s
  • Wemotec Midi fan Evo 90mm
  • Battery: 8S lipo 5000ma
  • Thick and Thin CA glue, 3/3

Small parts screws etc are not in kit; a list of  required small parts is included in the kit

Now some building pictures:

Rudder nice build up.

Stabilizer also build up.

Wing build up in 2 halves joined with spruce joiners ans some glass and epoxy.

Fuselage all formers ply and hollowed out to save weight.

Intakes easy set up with hard paper and balsa sheet inlet.

all sheeted nicely.

ready to paint.

Canopy parts are also cnccut included, pilots are not included.
