Bearcat 1000mm

Regular price €103,00 Sale price €95,00

Bearcat 1000

Cells 3s6000 lipo
Power req :Typhoon Xtreme 1814 kv 800-1200
Controls: 3x servo
Including: cad drawing, Canopy ,motor cowl intakes
Superb cad drawing lots of build pictures
Wood build precision kit,

Movie here

Photo instructions here do read the frontpage importand information there


      Design Features:

All Formers And Ribs CNC Cut
Unique Tab Lock Design
One Piece Design
hand launch grip incorporated
Battery Acces through wing opening or top hatch
Wing Area: 20dm2
Wing Span; 1030 mm
Flight Weight: Starts at 1500 grams
Wing Loading: 50gr dm2 to 75gr dm2
3 Channel Elevator, Ailerons & Throttle  (retract rudder optional)
      Kit Includes:
Instructions on drawing , build pictures download here,
It is a simple kit simple instructions, foto instructions mainly
Full Size Rolled Cad Plans With All Parts Shown
Vacuformed Canopy,cowl,, wing root intakes
There is no hardware in the Bearcat

Required to Complete:
Control Horns , Steering Cables hinges etc
3 Channel Radio
Batterys ,Motor etc

Build pictures.

Easy build wing. one piece

Easy build fuselage on main crutch self aligning structure

launch grip incorporated in wing

vacuumformed cowl makes it easy

Clear canopy , make pilot yourself
